產品說明
|
內 螺 紋 |
外 螺 紋 |
長度 mm |
參 考 鑽 孔 徑 | 最小鑽孔深度mm | ||||
| 公 制 | 英 制 |
外 徑 |
P | 塑 膠 | 鋁 合 金 | 鑄 鐵 | ||
| M 2.5 | NO.2 | 4.5 | 0.5 | 6 | 4.0 ~ 4.1 | 4.1 ~ 4.2 | 4.2 ~ 4.3 | 8 |
| M 2.6 | NO.2 | 4.5 | 0.5 | 6 | 4.0 ~ 4.1 | 4.1 ~ 4.2 | 4.2 ~ 4.3 | 8 |
| M 3 | NO.4 | 5 | 0.5 | 6 | 4.5 ~ 4.6 | 4.6 ~ 4.7 | 4.7 ~ 4.8 | 8 |
| M 3.5 | NO.6 | 6 | 0.75 | 8 | 5.3 ~ 5.4 | 5.5 ~ 5.6 | 5.6 ~ 5.7 | 10 |
| M4 | NO.8 | 6.5 | 0.75 | 8 | 5.8 ~ 5.9 | 6.0 ~ 6.1 | 6.1 ~ 6.2 | 10 |
| M5 | NO.10 | 8 | 1 | 10 | 7.1 ~ 7.2 | 7.3 ~ 7.5 | 7.5 ~7.6 | 13 |
| M6 | 1/4" | 10 | 1.5 | 14 | 9.0 ~ 9.2 | 9.2 ~ 9.3 | 9.3 ~ 9.4 | 17 |
| M8 | 5/16" | 12 | 1.5 | 15 | 10.6 ~ 10.8 | 11.0 ~ 11.2 | 11.2 ~ 11.4 | 18 |
| M10 | 3/8" | 14 | 1.5 | 18 | 12.6 ~ 12.8 | 13.0 ~ 13.3 | 13.2 ~ 13.4 | 22 |
| M12 | 7/16" | 16 | 1.5 | 22 | 14.6 ~ 14.8 | 15.0 ~ 15.3 | 15.2 ~ 15.4 | 26 |
| M14 | 1/2" | 18 | 1.5 | 24 | 16.6 ~ 16.8 | 17.0 ~ 17.3 | 17.2 ~ 17.5 | 28 |
| M16 | 5/8" | 20 | 1.5 | 22 | 18.6 ~ 18.8 | 19.0 ~ 19.3 | 19.2 ~ 19.5 | 27 |
| M18 | 22 | 1.5 | 24 | 20.6 ~20.8 | 21.0 ~ 21.3 | 21.2 ~ 21.5 | 29 | |
| M20 | 26 | 1.5 | 27 | 24.6 ~ 24.8 | 25.0 ~ 25.3 | 25.2 ~ 25.5 | 32 | |
| M22 | 3/4" | 26 | 1.5 | 30 | 24.6 ~ 24.8 | 25.0 ~ 25.3 | 25.2 ~ 25.5 | 36 |
| M24 | 7/8" | 30 | 1.5 | 30 | 28.6 ~ 28.8 | 29.0 ~ 29.3 | 29.2 ~ 29.5 | 36 |
